Description: 90°C, 600 Volts. Rated Extra Hard-Usage Flexible Stranding ,Oil Resistance, Excellent Abrasion Resistance
Application
Type SOOW flexible cords are permitted for use as specified by Article 400 and related articles of the 2011 National Electrical Code.The cords are designed for extra hard usage on industrial equipment, heavy tools, battery chargers, portable lights welding leads, marine dockside power, power extensions and mining applications.
Temperature rating and voltage rating
90°C and 600V
Standards and approval
UL62 – Flexible Cords and Cables
CSA 22.2 No. 49 – Flexible Cords and Cables
CSA & UL listed, UL File No. E518108
NEC Article 400
Construction
Conductor: Bare or tinned soft copper conductor
Separator: Polyester tape
Insulation: Oil and abrasion resistant EPR rubber insulation
Core identification
2 cores: black,white
3 cores:black, white, green
4 cores:black, white, green, red
Binder: Semi-conductive tape
Jacket: Oil and abrasion resistant CPE jacket
Technical Parameter
Size | Conductor Strands | Insulation Thickness | Jacket Thickness | Approx. Overall Diameter | Approx. Net Weight | ||||
mm | mils | mm | mils | mm | inch | kg/km | lbs/1000ft | ||
3X18AWG | 41 | 0.76 | 30 | 1.52 | 60 | 9.7 | 0.380 | 130 | 87 |
4x18AWG | 41 | 0.76 | 30 | 1.52 | 60 | 10.4 | 0.409 | 154 | 103 |
3X16AWG | 65 | 0.76 | 30 | 1.52 | 60 | 10.4 | 0.407 | 157 | 105 |
4x16AWG | 65 | 0.76 | 30 | 1.52 | 60 | 11.1 | 0.437 | 185 | 124 |
3X14AWG | 104 | 1.14 | 45 | 2.03 | 80 | 13.9 | 0.547 | 277 | 186 |
4x14AWG | 104 | 1.14 | 45 | 2.03 | 80 | 15.0 | 0.591 | 329 | 221 |
3X12AWG | 168 | 1.14 | 45 | 2.41 | 95 | 15.6 | 0.614 | 364 | 245 |
4x12AWG | 168 | 1.14 | 45 | 2.41 | 95 | 17.0 | 0.669 | 447 | 300 |
3X10AWG | 259 | 1.14 | 45 | 2.41 | 95 | 17.3 | 0.681 | 477 | 320 |
4x10AWG | 259 | 1.14 | 45 | 2.41 | 95 | 18.8 | 0.738 | 577 | 388 |
4X8AWG | 420 | 1.52 | 60 | 3.17 | 125 | 24.3 | 0.956 | 958 | 644 |
4X6AWG | 660 | 1.52 | 60 | 3.56 | 140 | 28.0 | 1.102 | 1316 | 884 |
4X4AWG | 1045 | 1.52 | 60 | 3.94 | 155 | 32.2 | 1.268 | 1845 | 1239 |
4X2AWG | 1650 | 1.52 | 60 | 4.32 | 170 | 37.0 | 1.457 | 2601 | 1747 |
