PVC Control Multicore (0.6/1.0kV)

PVC Control Multicore (0.6/1.0kV)

Multicore circular+earth, 0.6/1kV, V-90 insulated, PVC sheathed to AS/NZS 5000.1, Copper conductors, 90°C.

Construction characteristics

Colour                                                          Black

Conductor material                                  Copper

Conductor flexibility                               Class 2

Conductor shape                                     Circular

Insulation                                                 V-90

Outer sheath                                            PVC

With Green/Yellow core                       Yes

Dimensional characteristics

Number of earth cores                                    1

Electrical characteristics

Rated Voltage Uo/U (Um)                      0.6/1 kV

PVC Control Multicore (0.6/1.0kV) 1.5MM2(7/0.5MM)
No. of cores	Nom. overall dia.[mm]	Approx. weight [kg/100m]	Min. bend rad. during instal.  [mm]	Min. bend rad. installed    [mm]
2	10.1	16	91	61
4	11.9	24	105	71
6	13.1	26	120	79
8	15.4	30	140	92
10	16.1	35	145	97
12	17	40	155	100
20	20.1	59	180	120
30	24.3	83	220	145
50	19.4	129	265	175
PVC Control Multicore (0.6/1.0kV) 2.5MM2(7/0.67MM)
No. of cores	Nom. overall dia. [mm]	Approx. weight [kg/100m]	Min. bend rad. during instal.   [mm]	Min. bend rad. installed     [mm]
2	11.3	21	100	68
6	14.6	34	130	88
8	17.3	43	155	105
10	18.1	50	165	110
12	19	57	170	115
20	22.8	85	205	135
